Lowside Bike – 26″ Steel

Your BMX Bike All Grown Up

Lowside is like the grownup version of the bike you rode when you were a kid. It’s just as happy riding singletrack as it is parked outside your favorite drinking establishment.

Lowside is a single speed mountain bike. Singlespeeding has been a part of Surly’s DNA since day one when they launched the 1×1 Rat Ride. After a lot of Homie Fall Fests and more feats of strength than we can recall, we decided to discontinue it a couple years back. Lowside picks up right where the 1×1 left off.

“Some have dubbed the Lowside the ultimate pub cruiser.”

• Modern trail standards: dropper post compatibility, 44mm headtube, Gnot-Boost rear spacing, thru-axles
• Compatibility with most mountain bike standards makes it the perfect parts bin bike (no rim brakes allowed though)
• Spec’d in alternating years with 26 x 3” or 27.5 x 2.8” tires, the Lowside remains capable of running either option

Frameset
Frame: Surly Lowside, 4130 Chromoly, Natch tubing, double-butted main triangle, TIG welded, ED coated
Fork: Surly Lowside, 4130 Chromoly, Natch tubing, double-butted tapered fork blades, TIG welded, ED coated
Color: New Pig Smell

Drivetrain
Front Derailleur: N/A
Rear Derailleur: N/A
Cog: Surly 17T with spacer kit
Chain: KMC X10
Crankset: SRAM NX 32T
Bottom Bracket: SRAM Powerspline
Shifter: N/A
Brakes & Rotors: Tektro HD-M275 (HD-M276 on XS), 160/160mm, 6-bolt

Components
Headset: Cane Creek
Stem: Sunday Freeze Stem Top Load
Handlebar: Surly Sunrise
Grips / Bar Tape: Velo Black Lock-On
Seatpost: Promax SP-2019, 0 offset, 30.9mm diameter
Saddle: WTB Volt

Wheels
Front Hub: Novatec 15x110mm, 6-bolt, 32h
Rear Hub: Novatec 12x148mm, 6-bolt, 32h
Rims: ALEX MD40 26″
Tires: Surly Dirt Wizard 26×3″, 60tpi
Spokes: 14G Black

Other
Pedals: N/A
Complete Bike Weight: 31 lb 6 oz (Medium)
